HX60BCR Book Block Corner Rounding Trimmer Automatic Machine with Automatic Feeder and Stacker for Book Block Corner Rounding Process

Name: HX60BCR Book Block Corner Rounding Trimmer Automatic Machine with Automatic Feeder and Stacker for Book Block Corner Rounding Process
Brand: HXCP
Price: 29000 USD

Quality HX60BCR Book Block Corner Rounding Trimmer Automatic Machine with Automatic Feeder and Stacker for Book Block Corner Rounding Process for sale

Certification : CE

Warranty : 1 Year

Dimensions : 850×1100×1400mm

Material : Book Bloclk, Board Book

Brand Name : HXCP

MOQ : 1 set

Speed : 170pcs/min

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Maximum Length : 420mm

Model Number : HX60BCR

Price : USD 29000 per set

Maximum Width : 60mm

Delivery Time : 30 work days

Power : 0.75kw

Place of Origin : China

Model : HX60BCR

Packaging Details : Stretch Film with Wooden Case

Product Type : Trimming Machine

Application : Book Binding

Rated Voltage : 380v

Supply Ability : 30 sets/month

Paperboard Thickness : 1-5mm

Contact Now

HX60BCR Automatic Book Block Corner Rounding Trimming Machine

Description

HXCP HX60BCR Automatic High-speed Book Block Round Corner Trimming Machine is your ideal high productivity machine for the diary and notebook, perfect binding book, board book, and photo book's book block round corner trimming, can be connected with the three-knife trimmer, after the three-side trimmer, the book block will be sent to the trimmer stack with the automatic feeder, patented precise single-angle positioning trimmer system allows the book block＇s round corner is precise and smooth, and the corner mold is easy to change, automatic counting and stacking, all process is hand free and high efficiency. The speed can be 40 pcs/min, allowing the book block thickness from 10-60mm, and the different jobs conversion time only needs 15-20 mins.

HX60BCR Book Block Corner Rounding Trimmer Automatic Machine with Automatic Feeder and Stacker for Book Block Corner Rounding Process

MBO Stahl Paper Folder Paper Folding Machine CP GUK trifold for sale operator second hand used new manufacturer made in china shoie horizon Heidelberg Komori buckle leaflet brochure bookbinding post press auto folder combi combination HXCP Aster sewing machine thread sewing machine muller martini program control book block Smyth Sewn Binding HXCP bible notebook hardcover book case maker case making machine case maker hardcover case rigid box gift box board cardboard case lining hot melt gluing cold glue white glue BDM UNIVERSAL HÖRAUF Kolbus photobook

Parameters

Model Name	HX60BCR
Voltage	380V
*Dimension(LWH)*	33008501600mm
Weight	1000KG
Warranty	1 Year
Max Block Size	H380*W350mm
Min Block Size	H110*W100mm
Speed	30 knife/min
Cutting Thickness	10-150mm
Cutting Method	2 corners/time
Yield	99.5%±0.5%
Conversion Time	15-20min
Gas Source	200L/min @0.5-0.6Mpa
Power	AC220V/3KW
